3D Coordinate Measuring Machine (CMM)

Coordinate Measuring Machine (CMM) measurement utilizes a three-axis (X, Y, Z) coordinate system to perform high-precision inspection on workpiece surfaces. It enables accurate measurement of dimensions, tolerances, and geometric features, ensuring that products meet design specifications.

Measurement capabilities include:

• Dimensional measurement (length, diameter, hole positions)

• Geometric tolerances (flatness, perpendicularity, concentricity)

• Hole position accuracy and positional tolerance

• Surface and contour measurement

Through CMM measurement, machining errors can be effectively reduced, ensuring part accuracy and consistency while improving overall product quality and yield.
